This Electrolux washer repair guide will walk you through the steps of replacement of the lid switch/lock assembly for a top-load Electrolux washer. The washer includes a switch to determine whether the lid of the washer is opened. If the lid is open it means that the Electrolux washer won’t start.
The lid is held in place during the cycle with the lock. If the lid switch or lock isn’t working properly and the lamp for the lid blinks, your washer may require a replacement lid switch or lid lock. Because other problems have similar symptoms, we suggest that a local washer repair expert determine the root of the issue. If the lid switch/lock assembly is faulty, replace the assembly with a manufacturer-approved washer part. This repair guide addresses vertical modular washers. Vertical modular washers feature spinning at high speeds that remove water from the. The lid is kept secured to safeguard you from the spin components. Replace the lock on the lid on a top-load Electrolux washing machine
Switch off the electricity and water
Unplug the power cord from the wall outlet. Shut off the water supply valves on the Electrolux washer. Wear work gloves to protect your hands. Ask someone to help you remove the washer from the wall.
Lift the top of the panel
Cover the lid with tape so that it doesn’t fall open and cause damage to the console’s controls or your arms as you work. Then, pull the Electrolux washer forward to access the rear of the control console. The screws that hold the top of the Electrolux washer’s back and sides together are removed. Remove the screw from the wire cover and lift it off of the Electrolux washer. Slide the top panel about one-half inch forward before lifting the front panel by about one quarter inch. Keep the panel slightly elevated and push it back by about a quarter inch to take off the brackets. The top panel can be lifted up and put against the wall behind Electrolux washer.
Take the lid switch and lock off the top panel
Utilizing a 1/4-inch nut driver, remove the 2 screws which secure the lid switch and lock to the top panel. Unlock the lid switch assembly from the top panel. The wire harness has the lid switch/lock assembly. It is best to let it hang off the wire harness. To take the wire harness clips from the top panel, use the slot screwdriver. Pull out the wire harness clip made of white plastic located on the back of the front panel. The wire harness is connected to the electronic control board that is inside the console. Unclip the white plastic clip from the top of the panel. Don’t take off the clip made of white plastic or pull the wire harness out at this point.
Open the control console
Lower the top panel and rest it on side of the Electrolux washer. Move the washer forward to open the back panel of the console. Remove the two screws from the upper part of the back panel. Push back on the control panel while sliding a knife through the right edge of the control panel to release the clip for mounting. To let the console go continue the procedure on the left. Place the console on the top of the Electrolux washer.
Remove the lid switch/lock
Locate the wire harness connection for the lid switch/lock assembly at the rear of the control board. Lift the locking tab and remove the lid switch/lock assembly wire harness plug from the receptacle in the electronic control board. The lid switch/lock assembly wire harness through the hole located on the back of the top panel. This is where you release the clip made of white plastic. Release the tape on the lid, and then open the lid of the washer. Take the lid switch and lock out of the washer. Tape the lid shut again.
Install the new lid switch/lock assembly
The console should be re-snapped into its clips for mounting. Move the Electrolux washer to the back wall. Lift the top of the panel and prop it securely against the wall to the rear, behind the Electrolux washer. The wire harness end should be pushed into the opening in the top of the panel. The white wire harness clip needs to be inserted into the hole. The wire harness will be routed to the upper panel’s side. Then secure the wire harness in the clips located on the sides of the top panel.
Attach the lid switch or lock assembly on top of the panel. Fix it with the screws for mounting. Then, carefully lower the top panel. The panel should be pulled back by about a quarter inch to engage the brackets. To ensure that the panel is in place with the frame, pull the panel back about a quarter inch. To access the control board’s electronic circuit, unclip the clips and then lift the console. Connect the wire harness to the appropriate connector on the control board’s electronic circuit. The locking tab should be able to snap into position.
Reinstall the console
Place the console on the top panel and secure the mounting clips to secure the console to the top panel. Reinstall the screws at the top of the back of the console and tighten the screws with a firm grip.
Reinstall the screws on the back panel
Screws back into the top of the hinges that are on the rear of the control console. Tighten those screws firmly. The tabs should be placed on the left side. Then, align the slots on the left. Place the mounting screw. Secure the mounting screw to fix the cover to its the right position.
Bring back power and water
Turn on the valves for water supply. Connect the Electrolux washer to the outlet. Reinstall the Electrolux washer to the original location. We hope that now you are aware of how to replace the lid switch/lock assembly on top-loading Electrolux washer. If the lid switch or lock aren’t functioning properly, and the lock light flashes, it could indicate a need for a replacement.
